The Clockwork Card is a timing control hub designed to fit into the slot of the Stored Program Sound Source Model 208.
Inspired by Charles Cohen’s looping techniques, this card aims to provide an accessible way to control timing and create interesting rhythms. It offers multiple clocking options, 30 preset pattern banks, and the ability to shift and rotate rhythmic patterns across different destinations. The card also features two special modes (CLIX and Uncertainty Mode), and allows for customisation through its USB-C port.
Clocking Options
Select from three clock sources: the card’s internal clock generator, the 208’s pulser, or an external pulse (5 V or 10 V switchable). In external or pulser mode, the RATE knob serves as a clock divider from 1/1 to 1/16.
Dynamic Patterns
30 preset pattern banks, each containing four distinct rhythmic patterns assigned to the Sequencer, Envelope, Pulser, and Random destinations.
Destination Control
Each destination can be activated or deactivated with a switch. Rhythmic variations can be created by offsetting the Sequencer, Envelope, and Pulser patterns. Additionally, rotating patterns reassigns them to different destinations.
connectivity
The card interfaces with the 208’s to card and from card banana jacks. The inverter to card jack serves as an external clock input, while the inverter from card output provides a switchable sum of the pulse outputs or the master clock.
The preamp’s to card banana jack allows for voltage-controlled pattern rotation or resetting to the first step.
Note: If you are using the 208c with MIDI, the MIDI velocity data will be presented at the “from card” jack, which can interfere with the clock output. You can disable sending the clock to this jack with a DIP switch under the front panel.
Purchase
FIRMWARE
Download to edit patterns or rewrite functions.
The firmware upload procedure is found in the user guide.
